The Back-UPS RS offers high performance protection for your business and office computer systems. It provides abundant battery backup power, allowing you to work through medium and extended length power outages. It also safeguards your equipment from damaging surges and spikes that travel along utility, phone and network lines.
A distinguishing feature of the Back-UPS RS is automatic voltage regulation (AVR). AVR instantly adjusts both low and high voltages to safe levels, so you can work indefinitely during brownouts and overvoltage situations, saving the battery for power outages when you need it most.
To conserve electricity, you can configure the Back-UPS to recognize a Master device, such as a desktop computer or an A/V receiver, and controlled peripheral devices, such as a printer, speakers, or a scanner. When the Master device goes into Sleep or Standby mode, or turns OFF, the Controlled devices will shut down as well, saving electricity.
Shutdown software automatically powers down your computer system in the event of an extended power outage. Additional features like audible alarms, LED status indicators, user replaceable battery, push-button circuit breakers and plentiful outlets (including transformer-block spaced outlets) make the Back-UPS RS the perfect unit to protect your business' productivity from the constant threat of power problems and lost data.
A distinguishing feature of the Back-UPS RS is automatic voltage regulation (AVR). AVR instantly adjusts both low and high voltages to safe levels, so you can work indefinitely during brownouts and overvoltage situations, saving the battery for power outages when you need it most.
To conserve electricity, you can configure the Back-UPS to recognize a Master device, such as a desktop computer or an A/V receiver, and controlled peripheral devices, such as a printer, speakers, or a scanner. When the Master device goes into Sleep or Standby mode, or turns OFF, the Controlled devices will shut down as well, saving electricity.
Shutdown software automatically powers down your computer system in the event of an extended power outage. Additional features like audible alarms, LED status indicators, user replaceable battery, push-button circuit breakers and plentiful outlets (including transformer-block spaced outlets) make the Back-UPS RS the perfect unit to protect your business' productivity from the constant threat of power problems and lost data.
-
15.73 lbs
-
BR700G Features
Power-saving outlets automatically cut power to idle equipment to conserve electricity
Disconnected battery notification warns when a battery is not available to provide backup power
Boost and Trim Automatic Voltage Regulation (AVR) gives higher application availability by correcting low and high voltage conditions without using the battery
LCD graphics display for text and mimic diagrams that display modes of operation, system parameters and alarms -
# Ports: 6Communication Interface: USBConnector: Power NEMA 5-15Connector: Power NEMA 5-15 (F)Connector: Power NEMA 5-15 (M)
-
UPS, USB cable, documentation
-
Attributes: Coaxial line protectionAttributes: Line interactiveAttributes: RJ-45 line protectionColor: BlackEnclosure Type: InternalForm Factor: ExternalForm Factor: TowerWarranty Period: 3 yearsWeight Taxonomy: 15.76lbs
-
7.5"h x 3.6"w x 12.2"d
-
Output Connections: (3) NEMA 5-15R (Battery Backup), (3) NEMA 5-15R (Surge Protection)
Input Connection: NEMA 5-15P, 6ft power cord (attached)
(2) Coaxial connectors for surge protection
(2) RJ-45 connectors for network surge protection
(1) Data port (USB) -
Battery Run Time (max): 3.4minBattery Run Time (max): 4minPower Capacity (VA): 700VAPower Provided: 420Power Provided: 420WSurge Suppression: StandardSurge Suppression: YesVoltage Provided: 120VVoltage Provided: AC 120V
-
Input
Rated input voltage: 120VAC
Phase: Single phase 2 + ground
Frequency: 50/60Hz (autosensing)
Input voltage range (on AVR operation): Default setting 88-141V; Lower Limit Voltage Range 78-144V; Upper Limit Voltage Range 88-137V
Output
Maximum load: 700VA/420W
Output voltage: 115VAC + 8%
Frequency: 50/60Hz + 1
On-battery waveform: Stepped sine wave
Transfer time Maximum: 8ms
Batteries & Runtime
Included Battery Modules: (1)
Typical recharge time: 12 hours
Replacement Battery: RBC17
RBC Quantity: (1) -
This product is subject to our return policy. Please see our complete return policy for details.
-
17.45 lbs
-
Compliant Standards: FCC Part 15 BCompliant Standards: NOMCompliant Standards: REACHCompliant Standards: RoHSCompliant Standards: TUVCompliant Standards: UL 1778
-
39121011
-
3 Years
-
3 Years
-
Equipment protection policy: Lifetime $150,000
