Tripp Lite 1000VA Line-Interactive UPS w USB & (8) Outlets, 120V, 600W, 50 60 Hz, AVR, Eco Series (Eco1000LCD)

18.40 lbs

Allows Time to Back Up Critical Files During a Blackout:
Backup support allows you to work through short power failures, and gives you enough time to safely save files and shut down your system in case of a prolonged blackout. Backup time varies according to load, but the line-interactive UPS system should keep an energy-efficient desktop computer with LCD monitor powered as long as 40 minutes. During normal operation, incoming utility power keeps the UPS battery fully charged, so backup power will always be available. The hot-swappable internal batteries can be replaced by the user.

Connects Your Equipment to 8 NEMA 5-15R Outlets:
Four 5-15R outlets provide both battery backup and surge protection for your computer, monitor and other crucial components. The other four 5-15R outlets are surge-protected only for printers, scanners and other non-essential equipment. Four outlets—two battery/surge and two surge-only—are spaced apart from the others to accommodate bulky transformers. Three are ECO outlets designed to save you money and protect the environment (see below).

ENERGY STAR-Certified to Help You Save Money and Protect the Environment:
By meeting strict EPA efficiency guidelines, this ENERGY STAR-certified UPS system helps you save money and energy. An ECO power-saving option features three ECO outlets—two surge-only, one surge- and battery-protected—that turn off automatically when the device connected to the Battery Backup Master Outlet is powered down or in sleep mode. These outlets are recommended for printers, desk lamps and other non-essential peripherals that don’t need to be operational all the time.

Even Backs up Essential Data When You Aren’t Around:
Use the included USB cable to connect the USB-B port to your computer. Working with Tripp Lite’s free downloadable PowerAlert® software, this optional feature can enable safe unattended system shutdown and file saves in the event of a prolonged power failure when you aren’t around.

Automatic Voltage Regulation (AVR) Corrects Low-Voltage Conditions:
AVR protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts. The ECO1000LCD can correct brownouts as low as 86V back to nominal 120V power without drawing on the battery backup needed to support your equipment during a blackout.

316 Joules Fight Back Against Unexpected Power Surges:
A 316-joule surge suppression rating protects connected components from the harmful effects of power surges. Dual network data line surge suppression jacks protect a wired peripheral from dangerous surges on a single 10/100Base-T or dial-up network connection.

USB Charging Ports Keep Mobile Devices Fully Powered for Immediate Use:
Two 5V USB ports share 2.1 amps of maximum charge current for charging smartphones, tablets, MP3 players and other essential mobile devices compatible with USB chargers. These ports are intended only for USB charging, which is available when the UPS system is turned on and receiving utility power.

Combats Electromagnetic Interference That Can Harm Equipment:
Various electromagnetic and radio sources found in virtually every home and business can cause disruptive interference on the AC line. Known as EMI (electromagnetic interference) and RFI (radio frequency interference), this line noise is a common cause of performance problems and can lead to incremental hardware damage, data corruption and audio/video transmission problems. The ECO1000LCD incorporates technology that filters out disruptive line noise so that it won’t affect your equipment.

Easy-to-Read LCD Reports Real-Time UPS and Power Status:
The front-panel LCD displays a variety of UPS and site electrical conditions, including UPS operating mode, voltage, frequency, load level, battery charge level, wiring fault and estimated runtime remaining. A built-in audible alarm sounds to warn you of a low battery or overload co

UPS, USB cable, documentation

Typical Applications:
Protect your PC and other sensitive electronics against power surges, brownouts and blackouts
Operate essential equipment during short-term power outages using battery backup power
Shut down PCs, DVRs, routers and other equipment without data loss during long-term power outages
Turn off outlets connected to printers, desk lamps and other non-essential devices when not in use to save energy

11"H x 3.9"W x 11.33"W

COMMUNICATIONS
Communications Interface: USB (HID enabled)
Network Monitoring Port Description: Supports detailed monitoring of UPS and site power conditions
PowerAlert Software: For local monitoring via the UPS’s built-in communication ports, download PowerAlert Local software at http://www.tripplite.com/poweralert
Communications Cable: USB cable included
WatchDog Compatibility: Supports Watchdog application, OS and hard-reboot restart options for remote applications

USER INTERFACE, ALERTS & CONTROLS
Front Panel LCD Display: LCD screen offers detailed UPS status information, configuration options and error message reporting; STATUS INFORMATION input voltage, output voltage, input frequency, output frequency, load in VA, load in watts, battery charge level (4 bar graph), estimated runtime remaining (minutes) and UPS operating mode; CONFIGURATION OPTIONS Eco-mode off/on, alarm disable; ERROR MESSAGES Replace battery, overload and critical fault (see manual for complete listing)
Switches: ON / OFF / TEST Button offers power control and self-test operation; MUTE Button enables alarm-cancel and silent-mode opeation; SELECT Button is used to toggle LCD condition displays
Alarm Cancel Operation: Temporary alarm cancel and silent-mode operation is available using front-panel MUTE button (see manual)
Audible Alarm: Audible alarm indicates low battery, fault, overload and replace battery condition warnings

OUTPUT
Output Volt Amp Capacity (VA): 1000
Output kVA Capacity (kVA): 1.0
Output Watt Capacity (Watts): 600
Nominal Output Voltage(s) Supported: 110V; 115V; 120V
Nominal Voltage Details: 120v nominal output in battery mode
Frequency Compatibility: 50 / 60 Hz
Output Voltage Regulation (Battery Mode): 115V (+/- 5%)
Output Receptacles: (8) 5-15R
Output Receptacle Details: 4 UPS battery supported outlets with surge suppression + 4 surge suppression-only outlets
Output AC Waveform (AC Mode): Sine wave
Output AC Waveform (Battery Mode): PWM sine wave
Individually Controllable Load Banks: No

INPUT
Rated input current (Maximum Load): 12A
Nominal Input Voltage(s) Supported: 120V AC
UPS Input Connection Type: 5-15P
Input Circuit Breakers: 15A
UPS Input Cord Length (ft.): 6
Recommended Electrical Service: 15A 120V
Input Phase: Single-Phase

BATTERY
Full Load Runtime (min.): 2 min. (600w)
Half Load Runtime (min.): 7 min. (300w)
DC System Voltage (VDC): 12
Battery Recharge Rate (Included Batteries): 7 hours from 10% to 90%
Internal UPS Replacement Battery Cartridge: RBC51
Expandable Runtime: No

VOLTAGE REGULATION
Voltage Regulation Description: Automatic voltage regulation (AVR) maintains line power operation during brownouts as low as 86V (60Hz operation) / 105V (50Hz operation)
Undervoltage Correction: Input voltages between 86 and 105 are boosted by 23% (60Hz operation only)

SURGE / NOISE SUPPRESSION
UPS AC Suppression Joule Rating: 316
UPS AC Suppression Response Time: Instantaneous
UPS Dataline Suppression: 1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet
EMI / RFI AC Noise Suppression: Yes

LINE / BATTERY TRANSFER
Transfer Time: 6 milliseconds
Low Voltage Transfer to Battery Power (Setpoint): 86V during 60Hz operation (105V during 50Hz operation)
High Voltage Transfer to Battery Power (Setpoint): 142V

SPECIAL FEATURES
Green Energy-Saving Features: Greater than 95% efficiency - GREEN UPS


PHYSICAL
Installation Form Factors Supported with Included Accessories: Tower
Primary Form Factor: Tower
Cooling Method: Convection
UPS Housing Material: ABS

ENVIRONMENTAL
Operating Temperature Range: +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range: +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity: Up to 95%, non-condensing
AC Mode BTU / Hr. (Full Load): 98
AC Mode Efficiency Rating (100% Load): 96%

This product is subject to our return policy. Please see our complete return policy for details.

19.94 lbs

39121011

3 Years

3 Years

3-year limited warranty
Connected Equipment Insurance (US, Canada, & Puerto Rico): $250,000 Ultimate Lifetime Insurance
